Automatic Contact Lens Printing Machine by Full Servo

Electric Pad Printing Equipment

Our FC-161ANS model pad printer leads the way in energy conservation, saving an impressive 79.74% of electricity. But that's not all. We further incorporate laser positioning technology to ensure mechanical positioning accuracy of 0.01mm or less. Experience the difference of the FC-161ANS pad printing machine - a perfect combination of performance, sustainability, and professional excellence.

FC-450D

FC-450D

Automatic Contact Lens Printing Machine by Full Servo

This contact Lens pad printing machine has Servo Motor Driven Index Table – Precision Index Positioning. automatic pad cleaning system with programmable cleaning cycle. Servo Motor Driven Pad Printer with Linear Guideway and Ball Screw – Precision Positioning.Digital Setup of All Printing Parameters.CCD Camera with embedded Software.

Add RFQ RFQ results

Product Info

Automatic Contact Lens Printing Machine by Full Servo-FC-450D

4 Color Contact Lenses Pad Printer

Fine Cause's pad printing machine imported to industrial I.O.T., combine smart factory App, assist you to implement production management goals through synchronous monitoring.

■ Feature :

10 Inches HMI (65536 Color TFT Touch Panel Interface)
PANASONIC Programmable Logical Controller
Sheet Metal Body + Powder Coating – Neat Appearance, Stable Structure (Patent No. M456283)
Adjustable Pressure of Ink cup Holder against Steel Plate (Patent No. M311585)
Electronic Air Pressure Sensor – The machine stops when the pressure is lower than the set value
Servo Motor Driven Index Table – Precision Index Positioning
Automatic pad cleaning system with programmable cleaning cycle
Automatic Pressing/Positioning Mechanism and electronic Static dusting eliminator
8 mm UV-Resistant Yellow Acrylic Dusting Cover
Servo Motor Driven Pad Printer with Linear Guideway and Ball Screw – Precision Positioning
Digital Setup of All Printing Parameters
CCD Camera with embedded Software

Specifications

Model	FC-450D
Color	4
index Plate size(mm)	800
Cycles/hr	1900~2400 Pcs
Machine Size (cm)	L:610 W:300 H:250
Weight	1200KG
Pressure (kg/cm2 psi)	4~6
Power (A) Ampere	20
Voltage (V)	220V
Max. Printing Area (mm)	55
Max. Height of Printed Object (mm)	180mm
Height - Pad Stand to Steel Plate (mm)	100
Max. Steel Plate Size (mm)	L:200 W:100 H:10
