Max. height of printing stock: 101 cm

Screen printing equipment by frame heighten(FA-1000TSL)
📢 The Smart Screen Printing Machine can help you print on a wide range of large and small materials.

• Intelligent memory setting function: settings for different materials can be saved separately, allowing quick one-touch switching without needing to set up each time.

• Squeegee holder device can be extended to 4.5 ± 0.5 cm.

  • Easily removable; simple assembly and disassembly.

• Semi automatic screen printing machine adopts a magnetic squeegee clip (Patent No. M390871) makes the squeegee position can be slided easily and is simple to adjust and disassemble.

• T-shape platform able to exend 10cm outside (axis is firmly attached with a handle); adjustable area: ± 7 cm.

• Right side screen frame holder equipped automatic screen lifting mechanism.

• Right hand side stencil frame hanger equipped automatic screen lifting function that able to avoid issue of incomplete release of screen when printing via a large size screen.

• The maximum printable material height of the flat surface screen printer is 101 cm; printing test on computer case - printing stock height at 40 cm.

• Maximum printing area: 350*900 mm.

• This  semi automatic screen printer adpots 7.0 inches multicolor color touch screen with 65536 colors TFT;The man-machine interface can be easily switched to select the language:English, Indonesian, Vietnamese ,Thai andTraditional Chinese.

• Applied a programmable logic controller for easier function settings.

• Pneumatic cylinder RPM and multiple formula savings displayed on the screen; parameter settings.

• Left and right servo motor equipped a linear guideway and a ball screw rod that gives more stable printing performance.

• Screen frame holder adopted linear guideway that provides smooth and precise movement.

• The precise guideway design provides sturdy support to the squeegee holder mechanism, therefore the printing process can be finished with limited tolerance under precise control.

• This flat surface screen printer has production record: built-in smart bar chart displays machine .productivity, operating time, production rate, etc. in the past 30 days.

• This flat surface screen Printing equipment has WIFI function, which can combine with FINECAUSE APP to check the machine productivity anytime and anywhere.
