▲ The precision inspection of the pad printer before leaving the factory

FC-211GNC

Semi Automatic Pad Printing Machine-(Medium Type Single Color)Ink Cup 130Ømm

■ Pad printer features:

• The pad printer is equipped with Ø130mm ink cup that the printing range is larger. The printer is much lighter, which is designed not to take up space and easy to move.

• The pad printing machine can be equipped with peripheral mechanisms additionally such as slide rails, carousel, indexing table, suction, flipping, rotary, hair dryer racks, etc.

• There is a production history function for the pad printing machine: built-in smart bar chart that the productivity, running time, production speed, etc in the past 30 days can be shown.

• Connect to FineCause Smart Factory APP that the equipment productivity can be seen anytime and anywhere.

• The pad printer adopts a 7" color touch screen with 65536 color TFT and built-in 5 languages, traditional Chinese, English, Indonesian, Vietnamese, and Thai.

• With I/O (input/output), each sensor location is shown in whole area of the machine.

• With abnormal alarm display, it is convenient for production line personnel to eliminate abnormalities quickly.

• With electronic air pressure sensing, the device will notice automatically for insufficient air pressure.

• The printing pad usage count and cliché usage count can be set. When the set value is reached, the device will stop and notice automatically.

• The pad printing machine adopts PLC, which is easy to add or modify functions.

• Pneumatic cylinder running speed is displayed on the screen.

• Multiple groups of recipes can be stored and parameters can be set.

• The pad printing machine adopts pressure regulating ink scraping mechanism (patent number M311585), which can adjust the ink cup doctoring pressure easily.

• The pad printer is made by sheet metal + powder coating and the main body is formed integrally (patent number M453283).

• The Industry 4.0 I.O.T. (Internet of Things) is imported to the pad printers. WIFI function is combined with FineCause smart factory APP to help you accomplish production management goals through automatic monitoring.

• 【Pad printer thermostatic system】 can be added additionally. By increasing the ink temperature, the complete ink deposit can be maintained constantly. Printing conditions and quality are not affected by external ambient temperature.

■ Application:

special printing, toy printing, stationery printing, accessory printing, watch surface printing, electronic product printing, switch button printing, lighter printing, plastic printing, metal printing, semi-finished products printing, metal printer, glass printer, plastic surface printer, metal surface printer, ceramic glass printer for uneven surface printing

Additional precise indexing table making the printing accurate and easy to feed and dischage objects. Automatic peripheral equipment can be added according to the products to increase the productivity.

The best quality pad printing machine is in FineCause ~ find pad printer manufacturer to find FineCause.
