FC-161ARC-S6 Single-Color Ink Cup Pad Printer
Fine Cause's pad printing machine imported to industrial I.O.T., combine smart factory App, assist you to implement production management goals through synchronous monitoring.
■ Features :
-
pad printing machine use Electric Air Pressure Sensor
-
Servo Motor Driven Rotation Plate – Multi-Angle Rotation
-
Depressurized to fix the substrate – To avoid deformation from mechanical clamping
-
Ink Cup Pad Printer use 7.0" HMI touch panel with 65536 color TFT, built-in Chinese, English and Bahasa language.
-
Input & output full display
-
Abnormal warning display, convenient for quickly eliminate abnormalities
-
Digital pressure sensor, automatic alarm display for insufficient air pressure
-
Able to set the number of times which Pad-Print Printing is used, and it will automatically stop and display inform when the number is arrives.
-
-
PLC Programmable Logic Controller easy to add and modify function
-
Malfunction Detector – Message Displayed on Screen
-
Sheet Metal + Powder Coating Machine Body (Patent No. M456283)
-
Adjustable Ink-Scraping Pressure (Patent No. 311585)
Pad printer is one of the main series in Fine Cause's product line. In the past few years, we have been improving our production quality that made our products stand out among peers and advance forward to globalization. There are two major types of our pad printer: Ink Cup Pad Printer (Semi automatic pad printer/Custom pad printing machines) .
FineCause pad printer is able to expand automation equipment according to the material to increase production capacity.
The best pad printing machine in FineCause
~Looking for pad printing machine inquire to FineCause
FineCause is professional ink cups and ink plate pad printing machine, servo pad printing machine, custom pad printer manufacturer.
Specifications
Model | FC-161ARC-S6 |
---|---|
Color | 1 |
index Plate size(mm) | |
Cycles/hr | 1200~1800 Pcs |
Machine Size (cm) | L:70 W:40 H:135 |
Weight | 115 KG |
Pressure (kg/cm2 psi) |
4~6 |
Power (A) Ampere |
10 |
Voltage (V) | 220V |
Max. Printing Area (mm) |
55 |
Max. Height of Printed Object (mm) |
180mm |
Height - Pad Stand to Steel Plate (mm) |
100 |
Max. Steel Plate Size (mm) |
L:200 W:90 H:10 |
